應用在TWS藍芽耳機及行動裝置之超薄型功率電感

Ultra Low Profile Power Inductor applied for True Wireless Stereo headphones and portable devices


UHP160808TF-SERIES
UHP201208TF-SERIES

西北臺慶科技股份有限公司所研發生產薄型化鐵氧體電感，透過自動化繞線技術，提供高感值、低直流阻抗、小型化、薄型化的產品設計，透過新材料研發技術，亦可提供使用溫度範圍 -40 度~ 125度，廣泛應用於消費型電子產品電源處理及訊號處理，如手機、無線藍芽耳機、藍芽耳機充電裝置、小型面板、DOCKING..等。

The TAI-TECH new released of UHP160808TF/UHP201208TF-SERIES are designed specifically to meet miniaturization, high inductance, high withstanding current and low DCR values with low profile construction.

Based on the new material technology, the products are achieved with wide operating temperature range from -40 degrees to 125 degrees, which is widely used in power and signal processing in consumer portable devices, such as mobile phones, wireless Bluetooth headsets, Bluetooth headset charging devices, panels, DOCKING... etc.

產品特點:

1. 以自動化繞線生產技術增加產品穩定性。
2. 小型化尺寸設計 長1.6/2.0mm X 寬0.8/1.2mm X高0.8mm。
3. 適用於 -40 ~ 125度操作溫度範圍
4. 符合 RoHS、 REACH 、Lead Free

1. Fully automated production with high product consistency.
2. Slim product design. (1.6mm X 0.8mm X 0.8mm / 2.0mm X 1.2mm X 0.8mm)
3. Operating Range: -40~+125℃
4. 100% Lead(Pb) & Halogen-Free and RoHS compliant.

產品規格 Product Specifications

Dimension
