產品特色
卓越的條碼讀取性能
不論是紙本或是手機螢幕上的一維及二維條碼,皆可讀取
便利性的設計
簡潔的尺寸,可支援多種介面,加上安裝便利的設計,可以更符合使用者的需求
可遠程管理設備
透過遠程管理,可以降低多餘的成本支出
LED準心
免除雷射準心可能對使用者眼睛的影響
產品簡介
Vuguest 3330g採用耐用且靈活的外型設計,加上可讀取全系列一維及二維條碼,可迅速的導入產品設計中,節省開發設計所需要的時間。搭配Honeywell先進的解碼技術,Vuguest 3330g可直接讀取手機螢幕上的條碼,在Kiosks,自動販賣機,門禁系統,POS…等產品上是您理想的選擇。搭配上Honeywell TotalFreedom 軟體,甚至可判讀護照,機票…等的OCR條碼。Vugust 3330g使用LED準心而非雷射準心,可以避免在操作自助化裝置的時候,有可能對使用者眼睛的傷害。
|
MECHANICAL |
|
|
Dimension (L x W x H) |
74 mm x 50 mm x 26 mm |
|
Weight |
75 g |
|
Interface |
15-POS D-Sub connector |
|
PERFORMANCE |
|
|
Sensor |
CMOS, 844 x 640 pixels, Global shutter |
|
Motion Tolerance |
Up to 600 cm/s |
|
Field of View |
Horizontal: 42.4° Vertical: 33° |
|
Scan Angles |
Tilt: 360°, Pitch: ±45°, Skew: ±65° |
|
Symbol Contrast |
20% minimum print contrast ratio |
|
Symbologies |
|
|
Linear |
Codabar, Code 11, Code 128, Code 2 of 5, Code 39, Code 93 and 93i, EAN/JAN-13, EAN/JAN 8, IATA Code 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, MSI, GS1 DataBar, UPC-A, UPC-E, UPC-A/EAN-13 with Extended Coupon Code, Coupon GS1 Code 32 (PARAF), EAN-UCC Emulation |
|
2D |
PDF417, MicroPDF417, GS1 Composite, Aztec Code, Data Matrix, MaxiCode, QR Code, Chinese Sensible (Han Xin) Code |
|
Postal |
Australian Post, British Post, Canadian Post, China Post, Japanese Post, Korea Post, Netherlands Post, Planet Code, Postnet |
|
OCR (option) |
OCR-A, OCR-B, E13B(MICR) |
|
ENVIRONMENTAL |
|
|
Operating Temperature |
0°C to 40°C |
|
Storage Temperature |
-20°C to 70°C |
|
Humidity |
5% to 95% relative humidity, non-condensing |
|
Drop |
Designed to withstand 1.5m drops |
|
Vibration |
Withstands 5G peak from 22 to 300 Hz |
|
Ambient Light |
0 lux to 100,000 lux (total darkness to bright sunlight) |
|
Sealing |
IP53 |
| Download |
| 3330g Datasheet |
| 3330g Quick Start Guide |
