優異的動態掃描
Motion Tolerance最高可達6公尺/秒
超高速FPS
Frames Per Second提升至120FPS,讀取速度提高30%
可支援多種介面
可支援USB( 5V )介面或 TTL232 ( 3.3V ) Serial介面(2擇1),使用者可依需求做選擇
豐富條碼資料庫
可支援一維條碼,二維條碼,OCR條碼
百萬畫素鏡頭
對於小條碼/破損條碼有更佳的掃描效能
|
Physical Characteristics |
|
|
Dimensions (L x W x H): |
35mm x 35.5mm x 20.2mm |
|
Weight: |
70g |
|
Input Voltage: |
USB: 5V ; RS-232: 3.3V |
|
Current: |
RS-232: 250mA (Operating); 71mA (Idle); 2.7mA (Sleep Mode) USB: 200mA (Operating); 55mA (Idle); 2.1mA (Suspend) |
|
Performance Characteristics |
|
|
Barcode Engine: |
Honeywell N5780 |
|
Image: |
CMOS sensor 1280 x 800 pixels; Global Shutter; up to 60 frames per second |
|
Light Source: |
Aiming: Green Cross LED; Illumination: White LED |
|
Field OF View: |
Horizontal: 47° ; Vertical: 30° |
|
Scan Angles: |
Tilt: 360° ; Pitch:±60° ; Skew: ±60° |
|
Print Contrast: |
20% minimum print contrast ratio |
|
Motion Tolerance: |
6 meter per second |
|
Symbology Decode Capability |
|
|
1D: |
Codabar, Code 11, Code 128, Code 2 of 5, Code 39, Code 93 and 93i, EAN/JAN-13, EAN/JAN 8, IATA Code 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, MSI, GS1 DataBar, UPC-A, UPC-E, UPC-A/EAN-13 with Extended Coupon Code, Coupon GS1 Code 32 (PARAF), EAN-UCC Emulation |
|
2D: |
Codablock A, Codablock F, PDF417, MicroPDF417, Aztec Code, Data Matrix, Maxi Code, QR Code, Chinese Sensible(Han Xin) Code, DotCode, Grid Matrix |
|
Postal Codes: |
Australian Post, British Post, Canadian Post, China Post, Japanese Post, Korea Post, Netherlands Post, Planet Code, Postnet |
|
OCR: |
OCR-A, OCR-B, MICR-13, Digimarc Barcode |
|
Environmental |
|
|
Temperature: |
Operating: -30°C to 60°C ; Storage: -40°C to 70°C |
|
Humidity: |
0% to 95% relative humidity, non-condensing, at 60°C |
|
Ambient Light: |
0 – 100,000 lux |
|
Shock Specification: |
Designed to withstand 1.5m(5’) drops |
|
DOF |
|
|
100% U.P.C |
40mm to 490mm |
|
5 mil Code 39 |
60mm to 275mm |
|
20 mil QR Code |
27mm to 440mm |
|
*Performance may be impacted by barcode quality and environmental conditions. |
|
